1）接通冷却水，打开电源，将温度仪的温度调到800℃。
2）升温：接通电源约4小时即可以升至800℃，达到操作温度，温度自动控制。
3）进氨时（见配气房配置系统图）。见氨稳压器使用说明书，氨稳压器A2、A4的调节手柄全部旋出来。氨稳压器与氨罐阀门A1、A2连接好后，调节氨稳压器手柄，使工作压力达到0.05-0.08MPa.
4）通氨放空：打开放空阀，然后慢慢打开氨阀，使氨通入分解炉，约放空半小时。
5）约放空半小时后，如果无氨刺激性味道时。关闭放空阀，分解炉进入稳定运转状态。
2 纯化部分正常运转(按停机时的下一个工作状态开车)
氢氮混合气纯度达到要求后，，按照隔膜压缩型机说明书开车顺序，启动隔膜压缩型机。
1）如氢氮混合气贮罐压力低于0.02MPa，用氮气置换。打开氢氮混合气储罐放空阀门V3（见配气房配置系统图 ）放空。）氧气含量合格后关闭放空阀门V3。
2） 氢氮混合气储罐压力达到0.05MPa, 接通冷却水。打开阀门（见配气房配置系统图）F8，F10，启动隔膜压缩型机。
3） 开车时打开放空阀门V4，系统正常后关闭放空阀门V4
4）压力升到工艺要求，往车间送气。
Hydrogen components:
1) connected to the cooling water, turn on the power, the temperature of the instrument temperature to 800 ℃.
2) heating: power on for about four hours which can be raised to 800 ℃, reach operating temperature, automatic temperature control.
3) into ammonia (see Valve housing system configuration diagram). See ammonia regulator manual, ammonia regulator A2, A4 adjustment handle all spin out. Ammonia and ammonia tank regulator valve A1, A2 connected after adjusting ammonia regulator handle, the working pressure of 0.05-0.08MPa.
4) through venting ammonia: open vent valve, then slowly open the valve ammonia, ammonia pass into the decomposition furnace, vent about half an hour.
5) After emptying about half an hour, if there is no pungent taste when ammonia. Close the vent valve, calciner into the stable running condition.
2 purified part of the normal operation (operating state by next stop when driving)
After nitrogen and hydrogen purity requirements ,, A disc drive compact machine instructions sequentially, starting diaphragm compression machines.
1) such as nitrogen and hydrogen tank pressure is lower than 0.02MPa, purged with nitrogen. Open nitrogen and hydrogen storage tank vent valve V3 (see FIG configure the system with air room) vented. ) Qualified after oxygen content Close vent valve V3.
2) nitrogen and hydrogen tank pressure reaches 0.05MPa, turn on cooling water. Open the valve (see Valve housing system configuration diagram) F8, F10, start diaphragm compression machines.
3) while driving to open the vent valve V4, the system shut down properly vent valve V4
4) raising the pressure to process requirements, to the workshop aspirated.
|
